NIDEK YAG & SLT Laser System

YC-200 / YC-200 S plus

See and Illuminate Opacities in the Vitreous

The YC-200/YC-200 S plus is capable of seeing and illuminating opacities in the vitreous with NEW optional coaxial illumination tower, which makes visual axis and illumination axis coaxial. The tower optimizes visualization during posterior membranectomy, capsulotomy and iridotomy and also illuminates vitreous opacities with the on axis/off axis illumination.

Versatile Combo Lasers

The YC-200/YC-200 S plus can be easily connected to NIDEK’s Green Laser Photocoagulator (GYC-500), allowing treatment of a wider range of patients and indications. Space requirements are minimized, and the NEW optional combination adapter includes an illumination tower (split mirror illumination).

Efficiency Tailored
for SLT Treatment

The YC-200 S plus offers an advanced SLT mode. SLT-NAVI feature presents an intuitive display on the progress of laser treatment, providing the surgeon with important feedback.

Accurate Energy
Delivery Technology

The YC-200 S plus / YC-200 achieves 1.6 mJ plasma threshold in air¹, delivering accurate and robust treatments with lower energy.

Clear and Sharp Field of View for Better Treatment

An improved optical design that optimizes resolution and contrast, and an expanded focal depth provide a clear view of pathology and treatment.

Enhanced and Optimized Operating Distance

Maximized working distance allows easier manipulation of the contact lens, and the short operating distance decreases surgeon fatigue during treatment.

*Optional

Coaxial Illumination Tower*



The NEW optional tower** optimizes visualization during posterior membranectomy, capsulotomy and iridotomy and also illuminates vitreous opacities with the on axis/off axis illumination.


**Not pictured

1 of 5

Combo YAG/SLT/Green*



Easily connects to NIDEK’s Green Laser Photocoagulator (GYC-500), allowing treatment of a wider range of patients and indications. Space requirements are minimized, and the NEW optional combination adapter** includes an illumination tower (split mirror illumination).


**Not pictured

2 of 5

Optimized Operating Distance


Maximized operating distance allows easier manipulation of the contact lens, and the short operating distance decreases surgeon fatigue during treatment.

3 of 5

Functional User Console


An intuitive graphic user interface and easy-to-read touch screen color LCD allow quick and easy setup and verification of treatment parameters.

4 of 5

Unique Joystick

The S-switch on the joystick changes treatment settings without shifting gaze from the oculars. The ease of use allows surgeons an increased level of comfort during treatment.

5 of 5

1.6 mJ

Plasma Threshold in Air

Redefined Laser Delivery & Lower Energy

5.5°

Cone Angle in SLT Mode

with LED Illumination Light Source

360

Degree Rotation

with Dual Aiming Beam

±500

μm from 0

Focus Shift

5.7"

Color LCD Display

with Touchscreen

¹ A plasma threshold of 1.6 mJ is achieved in ordinary room conditions (in-house data).
